  • MQ022RG-CM Near IR Camera

Ximea MQ022RG-CM 2.2 MP Near IR CMOS Camera

Quick Overview

The XiQ Series is the industry standard Near IR camera USB 3.0 SuperSpeed specification.
Overview

2.2 Megapixel Near Infrared (NIR) enhanced CMOS.



Features:



  • Smallest dimensions: 26 x 26 x 30 mm, 31 grams
  • 2.2 MP at 170 fps (up to 340 with xiX)
  • With flat ribbon flex cable ideal for Embedded vision systems
  • USB3 Vision Compliant
  •


    Applications:



  • In-situ optical inspection camera
  • Fast process capturing, e.g. golf club swings
  • Intelligent Transportation Systems (ITS)
  • Open road tolling and Traffic monitoring
  • Industrial Automation
  • Machine Vision Facial Recognition
  • Motion Capture
  • Automotive crash testing
  • OCR/ OCV
  • 3D scanning
  • Robotic Arms
  • Material and Life science Microscopy
  • Ophthalmology and Retinal imaging
  • Medical Imaging
  • Flat panel inspection
  • Dental
  • Kiosks
  • Security
  • Biometrics
  • Specifications
    Resolution 2.2 MP 2048 × 1088 pixel
    Sensor type CMOS Matrix Near Infrared enhanced
    Sensor model CMOSIS CMV2000
    Sensor size 2/3"
    Sensor active area 11.27 × 6 mm
    Pixel size 5.5 µm
    Bits per pixel 8, 10, (12)
    Dynamic range 60 dB
    Frame rates 170 fps
    Image data interface USB 3.0
    Data I/O GPIO IN, OUT
    Power requirements 1.5 Watt
    Lens mount C or CS Mount
    Weight 31 grams
    Dimensions WxHxD 26 x 26 x 30 mm
    Operating environment 50 °C
    Customs tariff code 8525.80 30 (EU) / 8525.80 40 (USA)
    ECCN EAR99
