Toshiba IK-HD3H HD 3CMOS HD DVI-i Remote Head Camera

Toshiba IK-HR3H 1 Chip HD Remote Camera Head

1920 x 1080, 2.1MP 1/3" HD PS CMOS, DVI-i Remote Camera Head.Can use with:IK-HD3D
SKU
Toshiba IKHR3H
The IK-HR3H is Toshiba's latest innovation in 1-chip HD video cameras. This economical camera head incorporates unprecedented user controls and advanced noise reduction technology. The feature-rich progressive scan, 2.1MP 1080p, HD CMOS camera is compatible with Toshiba's 3-chip camera controller to produce exceptional color accuracy, high resolution, and increased sensitivity from an incredibly small package.  The IK-HR3H remote-head camera is ideally suited for 3D imaging, microscopy, scientific imaging, diagnostics, aerospace/aviation, specialty broadcast, and other applications where exceptional video performance, increased sensitivity and an ultra-small package is required.

The new IK-HD3D camera controller features innovative new capabilities such as binning mode for a 4X increase in sensitivity, image flip and mirror and greatly expanded user controls.  For even greater flexibility the controller is also compatible with the new IK-HD3H3-chip CMOS, 1080p camera head.


Features:

  • 2.1MP, progressive, 1/3" HD CMOS sensor
  • 1920 x 1080 Digital DVI output
  • High sensitivity and wide dynamic range
  • Up to 900 TV lines resolution
  • 5 User-configurable scene fi les to achieve exceptional color accuracy and control
  • Binning mode for 4x increase in sensitivity
  • Image flip and mirror
  • Switchable between 1080p and 1080i
  • Gen lock for 3D and multi-camera use
  • IK-HD3H and IK-HR3H Camera heads are interchangeable with controller
  • Remote control via RS232
  • C-mount lens mount

  • Applications:
  • 3D Imaging
  • Microscopy
  • Scientific Imaging
  • Diagnostics
  • Aerospace/Aviation
  • Broadcast
  • Image Sensor
    1 CMOS, 1/3 inch, 2.1MP progressive
    Output Resolution
    Horizontal: 1920, Vertical: 1080
    Resolution
    H: 900 TV lines standard
    V: 900 TV lines standard
    Sensitivity
    F7 standard (59.94 Hz setting)
    F7.7 standard (50 Hz setting)
    (at 2000 lx, 3000 K)
    Minimum Illumination
    9.9 lx (59.94 Hz setting)
    8.2 lx (50 Hz setting) at F2.2, 20 dB, BINNING: OFF
    19.8 lx (59.94 Hz setting)
    16.3 lx (50 Hz setting) at F2.2, 20 dB, BINNING: OFF
    S/N Ratio
    56 dB standard
    AGC: OFF, Gamma: OFF, Enhance: OFF
    Ambient Temperature 0°C to 40°C / 32°F to 104°F
    Ambient Humidity Less thank 90%
    Weight
    Approx. 34 g (1.2 oz)
    Dimensions W: 27.4 mm H: 27.4 mm D: 33 mm (1.08" x 1.08" x 1.3") Protruding portion is not included
