  • Sentech STC-SCS163POE | 1.6MP Camera | GigE Camera | Color Camera Image #1

Sentech STC-SCS163POE 1.6MP GigE Color Camera (CMOS)

Quick Overview

The STC-SCS163POE is a 1/1.8" CMOS (Sony IMX252) Progressive Scan Cased Mono Camera with 3.2 MEGAPIXELS, 2048 H X 1536 V, 216.2 fps, Global Shutter, C-Mount, Camera Link Output, and POCL.
Overview

Sentech's STC-SCS163POE is capable of capturing moving objects without any issue due to the camera has Global shutter sensor.



Features:



  • Imager Size: 1/1.8"
  • Color/Monochrome: Mono
  • Mount: C-Mount
  • CMOS 3.2M model has added to Camera Link series.
  • Sony Pregius Sensor provides high-quality images
  • This camera is capable of capturing moving objects without any issue due to the camera has Global shutter sensor.
  • Supported PoCL type, an external power supply is unnecessary
  •


    Applications:



  • Machine Vision
  • Industrial Imaging
  • Security
  • Surveillance
  • Specifications
    Resolution 3.2MP
    Color/Mono Color
    Frame Rate 216.2fps
    Effective Pixels 2048 x 1536
    Sensor Size 1/1.8"
    Cell Size (H x V, μm) 3.45 x 3.45
    Imaging Area (H x V x D, mm) 5.2 x 7.0
    Sensor IMX252
    Lens Mount C-Mount





    No Video available

    Sentech STC-SCS163POE 1.6MP GigE Color Camera (CMOS)
