  • Sentech STC-MBCM200U3V | USB3 Camera | Machine Vision Camera Image #1

Sentech STC-MBCM200U3V 2MP USB3, Monochrome Camera

Quick Overview

Sentech's STC-MBCM200U3V color camera features a 2/3" CMOSIS Sensor, 2 MP resolution, 167 fps, and an ultra compact 28 (W) x 28 (H) x 40 (D) mm size.
Overview

The STC-MBCM200U3V combines high megapixel resolution with a fast frame rate in order to provide the best machine vision camera on the market.



Features:



  • USB3 Vision Compliant
  • 167FPS
  • Global Shutter
  • Up to 64 Pixel Blemish Static Correction
  •


    Applications:



  • Machine Vision
  • Security
  • Factory Automation
  • Industrial Imaging
  • ITS
  • Specifications

     Imaging



    Model No

    STC-MCCM200U3V

    Image Sensor

    2/3" 2MP Color CMOS (CMOSIS: CMV2000)

    Active Picture Element

    2048 (H) x 1088 (V)

    Cell Size

    5.5 (H) x 5.5 (V) μm

      Function



    Scanning System

    Full scanning, Variable ROI

    Shutter Type

    Global Shutter

    Scanning Mode

    Full Scanning, Variable ROI (Horizontal and Vertical)

    Maximum Frame Rate (Full Scanning Mode)

    2M: 2048 x 1080: 167fps (Raw 8bit); Frame rate will drop if connected with the USB 2.0 port

    Maximum Frame Rate (AOI Mode)

    1280 x 1024: 177fps, 640 x 480: 370fps, Minimum AOI (32 x 32): 3500 fps

    Sync System

    Internal

    Video Output Format

    RAW 8bit / 10bit / 12bit (Default Raw 8bit)

    S/N Ratio

    Less than TBD digit (Gain 0 dB)

    Minimum Scene Illumination

    120

    Electronic Shutter

    Preset Free-run Mode: Exposure Time 22 μsec to16 sec (in full scanning mode); Preset Trigger Mode: Exposure Time 22 μsec to 16 sec (in full scanning mode)

    Gain

    -

    - Analog (Gain)

    Not supported

    - Digital (Gain)

    0 ~ 13.9 dB (Default 0dB)

    Offset (Analog)

    0 to 255 digit (for 12bit/pix data) 8bit: 0 to 15digit

    ROI

    ROI (Horizontal:32 to 2048 pixels / Vertical:32 to 1088 lines); (Default: 2048 x 1088) Adjustable Steps for offset: 2 pixels in horizontal direction and 2 lines in vertical direction Adjustable Steps for image size: 16 pixels in horizontal direction and 4 lines in vertical direction Adjustable Steps for ROI 8 Region, 16 pixels in horizontal direction and 4 lines in vertical direction

    Binning Function

    N/A

    Decimation Function

    x2, x4 Vertical Decimation

    ALC

    AE, AGC (Default AE:OFF, AGC:OFF

    White Balance

    Auto, Manual, One Push (Default: Manual)

    HDR

    Not supported

    Mirror Image

    Horizontal / Vertical / Horizontal and Vertical (Default: OFF)

    Pixel Defect Correction

    Up to 64 pixels (Default: ON)

    Operational Mode

    Free-run / Edge-Preset Trigger / Pulse Width Trigger

    User Setting Storage

    Supported

    Interface

    USB 3.0 Super Speed (USB 3.0 Micro B)

    Input / Output

    Three GPIO, One Camera Hardware Reset

    Power

    -

    - Input Voltage

    +5V (typ.) (Conform to USB Standard)

    - Communication

    Less than TBD W

      Mechanical



    Dimensions

    C Mount: 28 (W) x 28 (H) x 40 (D) mm *excluding the connectors

    Lens Mount

    C Mount

    Optical Filter



    Optical Center Accuracy

    Positional Accuracy in H and V directions: +/- 0.31 mm, Rotational accuracy of H and V: +/- 1.5 deg.

    Weight

    Approx. 52g

    Interface Connector

    USB Connector: USB 3.0 MicroB type / I/O Connector: HR10A-7R-6PB (Hirose) or equivalent

      Environmental



    Operating Temperature

    -

    - Minimum

    Environmental Temperature: -5°C

    - Maximum

    Camera housing temperature (top plate) shall not exceed 55°C

    Storage Temperature

    Environmental Temperature: -30 to +65 ºC, Environmental Humidity: 0 to 85%

    Vibration

    20 Hz ~ 200 Hz ~ 20 Hz (5 min. /cycle), Acceleration 10G, XYZ 3 directions 30 minutes each

    Shock

    Acceleration 38G, half amplitude 6ms, XYZ 3 directions 3 times each

    Standard Compliancy

    TBD (EMS: EN61000-6-2, EMI: EN55011)

    RoHS

    RoHS Compliant
