InVid Tech IMHD-20 (IMHD20) (1920x1080) 20" HD LED Monitor, HDMI, VGA, BNC
The IMHD-20 is a 20" Full HD LED Monitor that includes HDMI, VGA, & Looping BNC inputs.
SKU
InVid Tech IMHD-20
The InVid Tech IMHD-20 is the perfect space saver for Full HD monitoring in places where desktop area is at a premium.
Features:
- 1920 x 1080
- HDMI/VGA/BNC input
- BNC Output
- Multi-Language
- 3D Comb Filter
Applications:
- Security and Video surveillance
- Law Enforcement
- Microscopy
- Remote monitoring
- Ideal for Commercial and Industrial settings
- Risk Management
- Identity Management
- Government
- Warehouse surveillance
| Panel Size | 19.53” diagonal |
| Backlit Type | LED w/LED Backlight |
| Native Resolution | 1920x1080 |
| Contrast Ratio | 1000:1 |
| Native Aspect Ratio | 16:9 |
| Brightness | 250cd/m2 |
| Viewing Angle (H/V) | 170 / 160 |
| Pixel Pitch | 0.2265 x 0.2265mm |
| Response Time | <5ms |
| Composite Video Input | 1 BNC Input |
| Composite Video Output | 1 BNC output |
| VGA Input | 1 VGA (15 pin D-Sub) |
| Plug & Play Monitor | DDC Compatible (DDC 2B) |
| HDMI Input | 1 HDMI |
| 3D Comb Filter | Yes |
| De-interlaced | Yes |
| Screen Format | Yes |
| OSD Lock | Yes |
| OSD Language |
English, French, Spanish, German, Chinese, Dutch, Russian, Arabic |
| Video FormatScanning |
NTSC/PAL Auto Detect |
| TVL | 700 TVL |
| Power Consumption | <30W |
| Power Input | AC100-240V, 50/60Hz |
| Operating Temp | 32° F to 104° F |
| Operating Humidity | 10% to 85% (non-condensing) |
| Storage Temperature | -4° F to 140° F |
| Storage Humidity | 10% to 95% (non-condensing) |
| Safety & Regulartory | FCC/UL/RoHS |
| Cabinet | ABS Plastic |
| Color | Black |
| Stand | Desktop Stand with Tilt |
| VEGSA | 100 x 100mm |
| VESA Screw Type | M4 |
| Screw Length | >8mm |
| Dimension (Monitor Only) | 18.63 x 13.49 x 1.95 (inch) / 473 × 343 × 49.6 (mm) |
| Dimensions (Includes Stand) | 18.63 x 13.49 x 6.69 (inch) / 473 × 343 × 170 (mm) |
| Net Weight (Monitor Only) | 6.2lbs (2.8kg) |
| Gross Weight (Includes Stand) | 7.9lbs (3.6kg) |
| Package Weight | 11lbs (5.0kg) |
