Innovative Video Technology ULT-P4LIR (ULTP4LIR) 4 Megapixel Plug & Play Low Profile Camera
4 Megapixel IP Plug & Play Mini Low Profile Camera, WDR, 33’ IR Range, PoE/DC12V, SD Card Slot
SKU
Innovative Video Technology ULT-P4LIR
Features:
| Image Sensor | 1/3" progressive scan CMOS |
| Min Illumination | 0.01 lux @ (F1.2, AGC ON), 0 lux with IR |
| Shutter Time | 1/30s ~ 1/100,000s |
| Lens | 2.8mm @ F2.0 (4mm optional) |
| Angle Adjustments | - |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | True WDR 120db |
| Day & Night | IR cut filter with auto switch |
| Video Compression | H.264 / MJPEG / H.264+ |
| Alarm | 1/1 |
| Audio | 1/1, Built-in Mic |
| Dual Stream | Yes |
| Max. Image Resolution | 4 MP CMOS, 2688×1520 |
| Frame Rate | 20fps (2688×1520), 30fps (1920×1080) |
| Image Settings | Saturation, brightness, contrast, sharpness adjustable through client software or web browser |
| Network Storage | NAS |
| BLC | Yes, zone configurable |
| On Board Storage | Micro SD slot, up to 128GB |
| Alarm Trigger | Motion detection, tampering alarm, network disconnect, IP address conflict, storage exception, storage error |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos |
| Interoperability | ONVIF, PSIA, CGI |
| Security | User Authentication, reset button, flickerless, dual stream, heartbeat, mirror, watermark |
| General Functionalities | User authentication, watermark |
| Communication Interface | 1 RJ45 10M/ 100 M Ethernet interface |
| Operating Conditions | -22 °F ~ 140 °F (-30 °C ~ 60 °C) humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC +/- 10%, PoE (802.3af) |
| Power Consumption | Max. 5W |
| Ratings | IP66, IK08 |
| IR Range | Up to 30ft |
| Dimensions | 3.93" × 3.84" × 2.1" (99.8 x 97.5 x 53.3mm) |
| Weight | 0.55 lbs (250g) |
| Mounting Options | IUM-LRWM1, IUM-LRPM1, IUM-BRCM1*, IUM-BRPM1* |
