Fujinon HF818-12M (HF81812M) C-Mount 8mm Fixed 12MP Machine Vision Lens (C-Mount)
The Fujinon HF818-12M C-Mount 8mm Fixed Lens with a compatible 2/3" type sensor for capturing clear video.
SKU
HF818-12M
This 8mm fixed lens has a 56.9° horizontal field of view to monitor a specific area. This 12 MP-equivalent lens is designed for use in machine vision applications.
Features:
| Focal Length | 8mm |
| Iris Range (F no.) | F1.8-F22 |
| Angle of View | 56.9°x43.9° |
| Focus Range (From the front of the lens) (mm) | ∞‐100 |
| Operation Focus | Manual |
| Operation Iris | Manual |
| Filter Thread | M30.5 x 0.5mm |
| Mount | C-Mount |
| Sensor Size (max.) | 2/3" |
| TV Distortion (%) | -1.03 |
| Diameter (mm) | φ33x48.5 |
| Weight (ca.) (g) | 95 |
| Fixing knobs Bundled | 2 pcs. |
| Fixing Screws Bundled | 6 pcs. |
