CBC-Computar V5014-MP (V5014MP) 50mm Fixed Lens (C-Mount)
Computar V5014-MP 1" 50MM F1.4 Manual Iris C-Mount Lens, Ultra-Low Distortion, 2 MP
SKU
Computar V5014-MP
The Computar V5014-MP is a 1" 8mm F1.4 manual Iris C-Mount, Ultra Low Distortion, 2 Megapixel lens making it an ideal replacement for machine vision, factory automation, and security applications.
Features:
Applications:
| Focal Length | 50mm |
| Max. Apeture Ratio | 1:1.4 |
| Max. Image Format | 12.8mm x 9.6mm (φ 16mm) |
| Operation Range | Iris: F1.4 - F16.0 Focus: 0.5m - Inf. |
| Control | Iris: Manual Focus: Manual |
| Object Dimension at M.O.D. | 1" Type: 9.41 x 12.57 cm |
| Angle of View | D: 18.03° D: 12.49° 1" H: 14.50° 2/3" H: 10.02° V: 10.92° V: 7.53° |
| Operating Temperature | -10°C - +45°C |
| Effective Lens Aperture | Front: φ35.0mm Rear: φ16.0mm |
| Distortion | 1 type: -0.82%(y=8.0) |
| Back Focal Length | 14.55mm |
| Flange Back Length | 17.526mm |
| Mount | C-Mount |
| Filter Size | M40.5 P=0.5mm |
| Dimensions | φ 47.5mm x 48mm |
| Weight | 190 g |
