CIS VCC-HD3N 1/1.8 CMOS Full HD-SDI Color Camera

Full HD 60p output camera with 3G-SDI interface.

Features CIS original ISP, "Clairvu™", for superb imaging quality.

SKU
VCC-HD3N

Full HD 60p output camera with 3G-SDI interface. Features CIS original ISP, "Clairvu™", for superb imaging quality and high speed processing. Good for broadcasting applications in the compact footprint, 29x29x77mm. 3G-SDI I/F enables its superb quality images to be transmitted without compression via coaxial cable. AE, auto white balance, color correction, edge enhancement, noise reduction, gamma, external sync, and other function can be controlled. Available with or without casing.


Features:

  • Gen Lock function (3-values analogue signals or black burst)
  • 1080p, 60fps Full HD
  • 1080p/1080i/720p read out
  • 3G SDI I/F (HD SDI supported)
  • CIS ISP for various function
  • OSD function
  • Remote control unit (RU-100) is prepared
Color/Mono Color
Resolution 1920 x 1080
Output Format 1080p/1080i/720p
Sensor Model Name IMX265 (Pregius)
Shutter Type Global Shutter
Image Size 1/1.8 CMOS
Effective Pixels 2064 × 1544
Unit Cell Size (μm) 3.45 ×3.45
Power Consumption 4.0W
Power Requirement DC+9~+15V
Minimum Illumination DC+9~+15V
Sensitivity F5.6 2000lx
Shutter Variable Range 1/25s ~ 1/13600s
Interface 3G SDI, HD-SDI
Lens Mount CS / C Mount
Weight 92g
Dimensions (W) x (H) x (D)mm 29×29×77
