Blackmagic Design BDLKULSPRO UltraStudio Pro
The Blackmagic Design UltraStudio Pro has a built-in USB 3.0 interface that offers high-speed connectivity (4.8 Gb/s).
SKU
Blackmagic Design BDLKULSPRO
Transmits high-quality uncompressed 10 bit HD video with maximum real-time effects and the audio level meters help in accurate audio level calibration. With an innovative design, the UltraStudio Pro has a clean front-look having all the cables hidden. Made of solid metal, the unit is strong to withstand most harsh broadcast environments.
Features:
| SDI Video In & Out | SD/HD |
| Analog Video In & Out | Component & S-Video & Composite |
| HDMI Video In & Out | Yes |
| SDI Audio In & Out | 16 Channels |
| Analog Audio In & Out | 4 Channels Balanced |
| HDMI Audio In & Out | 8 Channels |
| AES Audio In & Out | 2 Ch In, selectable 6 Ch Out Unbalanced Sample rate converter on input |
| Computer Interface | USB 3.0 |
| Color Space Conversion | Hardware based real time |
| HD Down Conversion | Built-in, high quality hardware down converter always outputs to SD-SDI, composite and s-video when working in HD video formats. Component output can be switched between HD or SD. Selectable between letterbox, anamorphic 16:9 and center cut 4:3 styles |
| HD Up Conversion | Built-in, high quality hardware up conversion from SD to 720HD or 1080HD. Selectable between 4:3 pillarbox, 14:9 pillarbox and 16:9 zoom styles. HD outputs via HD-SDI and component analog |
| HD Cross Conversion | Built-in, high quality hardware cross conversion from 720HD to 1080HD and 1080HD to 720HD |
| Real time effects | Adobe Premiere Pro internal effects in DV, MJPEG and uncompressed |
| HD Format Support | 1080PsF23.98/24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080p23.98/24, 1080p25, 1080p29.97, 1080p30, 1080i50, 1080i59.94, 720p50, 720p59.94 and 720p60 |
| SD Format Support | 625/25 PAL, 525/29.97 NTSC and 525/23.98 NTSC and 480p |
| SDI Compliance | SMPTE 259M, 292M |
| Video Sampling | 4:2:2 |
| Color Precision | 4:2:2 10-bit |
| Color Space | 4:2:2 YUV |
| SDI Metadata Support | VITC read for 3:2 pulldown removal. VANC capture and playback using up to 3 lines of video in file HD RP188 |
| Audio Sampling | Television rate of 48kHz at 24 bit |
| Color Space | 4:2:2 YUV |
