  • Ximea MQ042RG-CM |  4.2 MP Cameras | Near IR Camera | CMOS Image #1

Ximea MQ042RG-CM 4.2 MP Near IR CMOS Camera

Quick Overview

The xiQ Series includes the latest CMOS sensors, Global Shutters and improved efficiency in the visible and NIR spectral ranges.
Overview

The MQ042RG-CM from Ximea is a USB 3 Near IR Extended camera.



Features:



  • Smallest dimensions: 26 x 26 x 30 mm, 32 grams
  • 4.2 MP at 90 fps (up to 180 with xiX)
  • With flat ribbon flex cable ideal for Embedded vision systems
  • USB3 Vision Compliant
  •


    Applications:



  • In-situ optical inspection camera
  • Fast process capturing, e.g. golf club swings
  • Intelligent Transportation Systems (ITS)
  • Open road tolling and Traffic monitoring
  • Industrial Automation
  • Machine Vision Facial Recognition
  • Motion Capture
  • Automotive crash testing
  • OCR/ OCV
  • 3D scanning
  • Robotic Arms
  • Material and Life science Microscopy
  • Ophthalmology and Retinal imaging
  • Medical Imaging
  • Flat panel inspection
  • Dental
  • Kiosks
  • Security
  • Biometrics
  • Specifications
    Resolution 4.2 MP 2048 × 2048 pixel
    Sensor type CMOS Matrix Near Infrared enhanced
    Sensor model CMOSIS CMV4000
    Sensor size 1"
    Sensor active area 11.27 × 11.27 mm
    Pixel size 5.5 µm
    Bits per pixel 8, 10, (12)
    Dynamic range 60 dB
    Frame rates 90 fps
    Image data interface USB 3.0
    Data I/O GPIO IN, OUT
    Power requirements 1.5 Watt
    Lens mount C or CS Mount
    Weight 32 grams
    Dimensions WxHxD 26 x 26 x 30 mm
    Operating environment 50 °C
    Customs tariff code 8525.80 30 (EU) / 8525.80 40 (USA)
    ECCN EAR99
