Aegis SDI-EH for Sony FCB-EH Series of HD Block Cameras

Quick Overview

The SDIEH Interface Board for Sony FCB-EH6300, FCB-EH cameras.
Overview

Features:

    •    SDI and HDSDI digital video output
    •    Analog HD and SD video output
    •    Automatic SONY camera recognition
    •    E nhanced signal quality : Low jitter, Sharp rising edges for long distance transmission
    •    Video format selection by micro switches
    •    Embedded colour bar & pathologic charts
    •    Embedded cross reticle
    •    TTL or RS232 VISCA dialog level
    •    5 to 12 VDC protected and EMC filtered power supply input

Specifications
Function
Spec
Digital video output
SDI : 576i, 480i
HD-SDI1080 60i, 1080 50i, 720 60p, 720 50i
Analog video output
VBS : PAL , NTSC
YC
Video output configuration
Micro switch
Camera setting
RS232 , RX , TX , VISCA
Power
6 to 12 VDC, 6 W ( including camera)
Environmental
0°C to 60°C
Storage
-20°C to 60°C
Dimensions
48 ( H)x 45 (L)x 20 ( P)
