Kowa LMVZ990-IR (LMVZ990IR) 6.5-52mm 1/2" Format Varifocal Lens
1/2", F1.8-F16, C-Mount.
SKU
LMVZ990-IR
For applications requiring long-range surveillance, the LMVZ990A-IR has the largest focal range of any Day and Night Varifocal lens in the industry. By using Kowa's eXtra-low Dispersion glass, these lenses provide crisp color images in the daylight and high definition black and white images at night without the need for refocusing.
Features:
| Focal Length (mm) | 9~90 (10×) |
| Image Size (mm) | 6.4×4.8 (Φ8) |
| Iris Range (F-stop) | F1.8 ~ F16 |
| Focusing Range (m) |
0.3 ~ ∞
|
| Control | Iris: Manual Focus: Manual |
| Shooting Range at M.O.D. (mm) | W252.7×182.5/T4.2x3.1×5.4 |
| Angle Of View (Degrees) | 1/2": W41.1×30.8/T5.4×4.0 1/3": W30.3×22.5/T3.1×2.4 |
| TV Distortion (%) | W−4.3/T0.3 |
| Back Focus in Air (mm) | W15.4/T11.7 |
| Mount | C-Mount |
| Filter Thread (mm) | M43×P0.75 |
| Size (mm) | Φ45×93 |
| Weight (g) | 194 |
| Temperature Range | −10°C~+50°C |
