Kowa LM8XC 4/3" Format 8mm Megapixel Lens
4/3" Format, 8mm, Megapixel Lens.
SKU
LM8XC
The Kowa 4/3" megapixel XC lens series provides a large image format of Φ23mm(C-mount). These high precision aspherical lenses greatly reduce distortion and produces a high definition picture. XC lenses maintain megapixel resolution throughout the entire image even if the iris is fully open. In addition, Kowa's wide-band multi-coating effectively reduces glare and refraction.
Features:
| Focal Length (mm) | 8.5mm |
| Image Size (mm) |
18.4×13.8 (Φ23) |
| Iris Range | F2.8~F22 |
| Focusing Range (m) |
.1~∞
|
| Control |
Iris: Manual
Focus: Manual |
| Shooting Range at M.O.D. (mm) |
238.4(H)×179.1(V)
|
| Angle of View (Degrees) |
4/3": 93.5×77.1
1": 72.9×57.9 2/3": 53.8×41.6 |
| Resolution (Center, Corner) |
160lp/mm, 80lp/mm
|
| TV Distortion (%) |
0.12
|
| Back Focus in Air (mm) |
12.9
|
| Mount |
C-Mount
|
| Filter Thread (mm) |
M72×P0.75
|
| Size (mm) |
Φ74×82.5
|
| Weight (g) | 245 |
| Temperature Range | −10°C~+50°C |
