  • Kowa LM8JC3M2 Image #1

Kowa LM8JC3M2 2/3" Format 8mm Megapixel Lens

Quick Overview

2/3", 8mm, Megapixel Lens.
Overview

Features:

  • Kowa's wide-band multi-coating effectively decreases glare and refraction and produces a high transmission from the visible to NIR wavelength range.
  • Kowa's floating mechanism system virtually eliminates optical aberrations from close distance to infinity
  • Low distortion
  • Excellent corner brightness
  • Applicable on 1/1.2" as well
  • Specifications
    Focal Length (mm) 8 mm
    Image Size (mm) 8.8x6.6 (Φ11)
    Iris Range F 1.4 - Close
    Focusing range (m) 0.1 - ∞
    Iris Manual
    Focus  Manual
    Shooting range at MOD (mm) 120.3 x 90.0
    Angle of View (Degrees) 2/3": 56.5 x 43.9
    1/1.8": 47.4 x 36.3
    1/2": 42.6 x 32.5
    TV Distortion (%) -0.6
    Back Focus in Air (mm) 9.5
    Mount C-Mount
    Filter Thread (mm) M27xP0.5
    Size (mm) Φ34 x 41.6
    Weight 90
    Temperature Range -10°C - +50°C
