  • Fujinon HF12XA-5M Image # 1

HF12XA-5M: Fujinon 2/3" 12mm 5MP Machine Vision Lens (C-Mount)

Quick Overview

HF12XA-5M: Fujinon F1.6 to F16, Angle Of View (H x V) 40.1° × 30.3°.
Overview

The Fujinon HF-XA-5M series features 4D High Resolution, which mitigates resolution degradation even when changing a working distance or aperture value. The lenses' compact design accommodates installation at a variety of conditions at production lines. The series is available in six models of various focal lengths, allowing users to choose the optimum model according to their usage.

Features:

  • C Mount for 2/3" Sensors
  • Manual Focus and Iris
  • Adjustable Locking Focus and Iris Knobs
  • f/1.6 to f/16
  • M25.5 Threaded Front for Filters

  • Applications:

  • Product Inspection Applications
  • Specifications
    Focal Length 12mm
    Iris Range F1.6-F16
    Angle of View (H x V)
    *Mounted to 2/3" sensor cameras
    40.1° x 30.3°
    Focus range (from front of the lens) (mm) ∞-100
    Operation Focus Manual
    Operation Iris Manual
    Filter Thread (mm) M25.5 x 0.5
    Mount C-Mount
    Sensor Size (max.) 2/3"
    Back focal distance (in air) 11.89 mm
    Flange back 17.526
    Exit pupil position (from image plane) -123.16
    Front principle point (from Mount) -24.44
    Rear principle point (from Mount) 5.13
    Distance between the principal points 29.57
    TV distortion (%) -1.3
    Diameter (mm) φ29.5 x 51.5
