  • Fujinon HF1218-12M Image 1

HF1218-12M: Fujinon 2/3" 12mm F1.8 Manual Iris 12MP Machine Vision Lens (C-Mount)

Quick Overview

The 12mm Fixed Lens from the Fujinon HF1218-12M is compatible with a 2/3" type sensor for capturing clear video.
Overview

This 12mm fixed lens has a 39.3° horizontal field of view to monitor a specific area. This 12 MP-equivalent lens is designed for use in machine vision applications.

Features:

  • For 2/3" Type Sensors
  • C-Mount
  • f/1.8-2.2 Aperture Range
  • 30° Field of View
  • Specifications
    Focal Length 8mm
    Iris Range (F no.) F1.8-F22
    Angle of View 56.9°x43.9°
    Focus Range (From the front of the lens) (mm) ∞‐100
    Operation Focus Manual
    Operation Iris Manual
    Filter Thread M30.5 x 0.5mm
    Mount C-Mount
    Sensor Size (max.) 2/3"
    TV Distortion (%) -1.03
    Diameter (mm) φ33x48.5
    Weight (ca.) (g) 95
    Fixing knobs Bundled 2 pcs.
    Fixing Screws Bundled 6 pcs.
