Interface boards



Interface Board Reference Chart
Model #   Camera Outputs Size Accessories
  FCBER8300  FCBH11   FCBSE600   FCBEH   FCBEV  FCBMA  HDSDI   HDMI   4K   HD COMP   SD  USB 3.0

Dimension (mm)

Included
HDMI 4K Interface Board                   63 x 47mm Board, Cables
HDMI-4K-GM                     46 x 30mm  Board, Cables
SDI-EV-AS                       46 x 42mm

Board, Cables,
Bracket, Screws

SDI-H11                  48 x 45mm

Board, Cables,
Bracket, Screws

SDI-EH                48 x 45mm

Board, Cables,
Bracket, Screws

SDI-H11-MCX                  48 x 45mm

Board, Cables,
Bracket, Screws

SDI-EH-MCX                48 x 45mm

Board, Cables,
Bracket, Screws

HDMI-H11                    48 x 45mm

Board, Cables,
Bracket, Screws

HDMI-EH                  48 x 45mm

Board, Cables,
Bracket, Screws

HDMI-EV                48 x 45mm Board, Cables
SDI-EV                  48 x 45mm Board, Cables
SDI-H11-GM                42 x 46mm Board, Cables
SDI-EH-GM              42 x 46mm Board, Cables
SDI-HDMI-H11-GM                42 x 46mm Board, Cables
SDI-HDMI-EH-GM              42 x 46mm Board, Cables
USB-3.0-EH-H11                        48 x 45mm Board, Cables
AVP-MA130-USB3-BC                      ✓  41.5 x 20mm Board, Ribbon Cable
AVP-MA130-USB3-NE                      41.5 x 20mm

Board, Ribbon Cable, PCI-E Card, USB 3 Cable

AVP-MA130-USB3-E                      41.5 x 20mm

Board, Ribbon Cable,
USB 3 Cable

SDI-FIBER-EH-GM                  60 x 52mm Board, Cables
SDI-HDMI-EV-GM                 Board, Cables
SDI-H11-AS                  42 x 46mm

Board, Cables,
Bracket, Screws

SDI-EH-AS                  42 x 46mm

Board, Cables,
Bracket, Screws

SDI-SE600-AS                      48 x 48mm

Board, Cables,
Bracket, Screws

IFBEX232HD                  42 x 42mm Board, Cables
USB3.0-EH-EV-GM             45 x 40mm Board, Cables
